Galfan Coated Alloy Galvanized Wire Gabion Mesh Basket Cage
Product Details:
| Place of Origin: | China, China |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100.0 Pieces |
|---|---|
| Packaging Details: | 2x1x1bundle |
| Supply Ability: | 10000 Piece/Pieces per Day |
|
Detail Information |
|||
| Place Of Origin: | China | Material: | Alloy |
|---|---|---|---|
| Delivery Time: | 22-30 Days | Alloy: | Galfan Galvanized Alloy Wire, Zn-10%AL |
| PVC Thickness: | PVC Coating Norminal Thickness 0.5mm | Tensile Strength: | Tensile Strength 350-550N/mm2 Per EN 10223-3:2013 |
| Wire Tolerance: | Wire Tolerance Is Per EN 10218 (Class T1) | Size Of Gabions: | 2*1*1M Or Customized |
| Steel Wire Diameter: | 2.7mm Or Customized | Selvedge Wire: | 3.4mm |
| Mesh Size: | 8*10CM For Gabion Boxes | PVC Color: | Customized To RAL Standards |
| Coutry Of Origin: | China | ||
Product Description
Product Description
Specification
Wire Tolerance | Wire tolerance is per EN 10218 (Class T1) |
Elongation | Elongation > 8% per EN 10223-3:2013 |
Mass of GALFAN | Galfan coating meets EN 10244-2 (table 5 - class A) |
GALFAN Adhesion | Galfan adhesion meets EN 10244 |
Accelerated Test | Out wearing accelerated test is per EN ISO 6988 |
PVC technical characteristics and Aging Resistance | Technical characteristics and aging resistance of PVC coating comply with EN 10245-1 |
Resistance to UV radiation | Resistance to UV radiation: the tensile strength and elongation at break of the base compound after 2500 hours of exposure to QUV-A (ISO 4892-3 mode 1) do not change more than 25% from the initial test results. |
Chemical Resistance | Chemical resistance: the PVC resist the chemical agents in concentrations that are representative of soil and water normally found in civil works. |
Aging test in salt spray | Outwearing accelerated ageing test in salt spray: when the PVC coated wire mesh is subjected to the neutral salt spray test (ISO 9227) after 6000 hours of exposure the mesh does not show more than 5% of DBR (Dark Brown Rust). |
Resistance to UV abrasion | Resistance to abrasion: the PVC coating does not expose metal wire when tested in accordance with procedure described in part 4.1.2.1 of EN 60229:2008, after 100,000 cycles with a vertical force of the steel angle of 20N. |
Wire Mesh tensile strength | The nominal tensile strength of the wire mesh is as per EN 10223-3:2013. |
Wire mesh punch strength | The punch strength of the wire mesh is as per UNI 11437 and ISO 17746. |
PVC crack test | When the mesh is tested at 50% of the nominal tensile strength in accordance with EN 10223-3:2013, the wires will not show cracks in the organic coating within the double twist region. |
Manufacturing Style | Hexagonal Woven Mesh |
Process
Seaming
unpack
Quality inspection
Press package
Finished product
