Gabion baskets are used in many situations, including the stabilization of earth movement and erosion, river control, reservoirs,
canal refurbishment, landscaping and retaining walls. They can be manufactured in welded mesh or woven wire. Welded mesh gabions are faster to erect and do not need tensioning. This allows them to keep their shape, to be free from bulges and depressions and fit easily against the wall. It is possible to cut holes in them if needed to pass pipes etc through and they can be machine
filled.
 |
Galfan Coated Alloy Gabion Basket With 0.5mm PVC Coating Tensile Strength 350-550N/mm2
Product Details:
| Place of Origin: | China, China |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100.0 Pieces |
|---|---|
| Packaging Details: | 2x1x1bundle |
| Supply Ability: | 10000 Piece/Pieces per Day |
|
Detail Information |
|||
| Place Of Origin: | China | Material: | Alloy |
|---|---|---|---|
| Delivery Time: | 22-30 Days | Alloy: | Galfan Galvanized Alloy Wire, Zn-10%AL |
| PVC Thickness: | PVC Coating Norminal Thickness 0.5mm | Tensile Strength: | Tensile Strength 350-550N/mm2 Per EN 10223-3:2013 |
| Wire Tolerance: | Wire Tolerance Is Per EN 10218 (Class T1) | Size Of Gabions: | 2*1*1M Or Customized |
| Steel Wire Diameter: | 2.7mm Or Customized | Selvedge Wire: | 3.4mm |
| Mesh Size: | 8*10CM For Gabion Boxes | PVC Color: | Customized To RAL Standards |
| Coutry Of Origin: | China | ||
Product Description
Product Description
Woven Gabions
Specification
Wire Tolerance | Wire tolerance is per EN 10218 (Class T1) |
Elongation | Elongation > 8% per EN 10223-3:2013 |
Mass of GALFAN | Galfan coating meets EN 10244-2 (table 5 - class A) |
GALFAN Adhesion | Galfan adhesion meets EN 10244 |
Accelerated Test | Out wearing accelerated test is per EN ISO 6988 |
PVC technical characteristics and Aging Resistance | Technical characteristics and aging resistance of PVC coating comply with EN 10245-1 |
Resistance to UV radiation | Resistance to UV radiation: the tensile strength and elongation at break of the base compound after 2500 hours of exposure to QUV-A (ISO 4892-3 mode 1) do not change more than 25% from the initial test results. |
Chemical Resistance | Chemical resistance: the PVC resist the chemical agents in concentrations that are representative of soil and water normally found in civil works. |
Aging test in salt spray | Outwearing accelerated ageing test in salt spray: when the PVC coated wire mesh is subjected to the neutral salt spray test (ISO 9227) after 6000 hours of exposure the mesh does not show more than 5% of DBR (Dark Brown Rust). |
Resistance to UV abrasion | Resistance to abrasion: the PVC coating does not expose metal wire when tested in accordance with procedure described in part 4.1.2.1 of EN 60229:2008, after 100,000 cycles with a vertical force of the steel angle of 20N. |
Wire Mesh tensile strength | The nominal tensile strength of the wire mesh is as per EN 10223-3:2013. |
Wire mesh punch strength | The punch strength of the wire mesh is as per UNI 11437 and ISO 17746. |
PVC crack test | When the mesh is tested at 50% of the nominal tensile strength in accordance with EN 10223-3:2013, the wires will not show cracks in the organic coating within the double twist region. |
Manufacturing Style | Hexagonal Woven Mesh |
Tianjin Cn-Gabion Co., Ltd. Gabion boxes and Solutions
Process
Company Profile
Thanks for your interest in Tianjin Cn-Gabion Co., Ltd. Cn-Gabion is a professional wire mesh products manufacturer that supplies you better solutions and the quality wire meshes. This is your one-stop wire mesh solution provider. Be assured that our dynamic team is always moving forward, researching, and seeking to provide you with only the best.
Cn-Gabion, originally founded in 2011, has been the leading manufacturer of wire mesh products. We are well respected in the industry for being trustworthy in quality and service. To meet and exceed customers' expectations have been our core value since establishment, which promotes our senior executives to make proactive changes constantly in the market.
Our mission is to deliver values for our customers by providing them superior quality, exceptional service and competitive pricing, which brings you a competitive advantage in the market. We devote ourselves to becoming an indispensable wire mesh supplier to customers and to meet their demands and exceed their expectations in quality, delivery and cost through continuous improvement, innovation and customer interaction.
Gabion Product Applications
Customer Visit
Packing & Delivery
FAQ
Q: Where is your factory and which port is close to you?
A: Anping Hebei. Tianjin Xingang Port.
Q: What’s your MOQ?
A: MOQ is around 200pcs, negotiable.
Q: What is your payment term?
A: Payment:T/T 30% in advance, the balance before delivery, or go throught Alibaba Trade Assurance.
Q: How do we do if we have not received our ordered numbers?
A: Please send us pictures or any evidence, we will compensate the missed number free.
Q. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the courier cost. And all the sample cost will be refunded after you place the order.
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the courier cost. And all the sample cost will be refunded after you place the order.
Q. Do you test all your goods before delivery?
A: Yes.
A: Yes.
Q: All costs will be clear?
A: Our quotations are straightforward and easy to understand. Won’t cause any extra cost.
Q: How long warranty does your company can provided for fence product?
A: Our product can last for 10 years at least. Usually we will provide 5-10 years guarantee.
A: Our product can last for 10 years at least. Usually we will provide 5-10 years guarantee.
Q: How can I assure my payment?
A: You can place the order through Trade Assurance on Alibaba..
A: You can place the order through Trade Assurance on Alibaba..
Want to Know more details about this product
