High Strength Premium Woven Chain Link Fencing For Enhanced Security
Product Details:
| Place of Origin: | Hebei, China, China |
| Brand Name: | CN-Gabion |
| Model Number: | CG-Y21-CL-001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100.0 Pieces |
|---|---|
| Packaging Details: | 1. woven bags of the above and bottom2. In roll, waterproof paper on the side and our side with weave bag, carton, wooden case,pallet.3. according to customer requirements. |
| Supply Ability: | 9999 Roll/Rolls per Week |
|
Detail Information |
|||
| Place Of Origin: | Hebei, China | Brand Name: | CN-Gabion |
|---|---|---|---|
| Model Number: | CG-Y21-CL-001 | Material: | Galvanized Iron Wire |
| Type: | Chain Link Mesh | Application: | Fence Mesh |
| Delivery Time: | 15-21 Days | Alloy: | Galfan Galvanized Alloy Wire, Zn-10%AL |
| Tensile Strength: | Tensile Strength 350-550N/mm2 Per EN 10223-3:2013 | Wire Tolerance: | Wire Tolerance Is Per EN 10218 (Class T1) |
| Roll Of Chainlinked: | 25x1.5, 50x1.5 Or Customized | Steel Wire Diameter: | 3.0, 4.0, 5.0 |
| Mesh Size: | 50x50 | Coutry Of Origin: | China |
| Manufacturing Style: | Woven | ||
Product Description
Product Description
* A roll of inexpensive and reliable chain link mesh; use it to build a privacy fence or add security to your home, farm,
business, construction site, or more
* Works best when combined with ALEKO brand chain link posts and top rails, sold separately, to make a full chain link fence system
* Also sold as a pre-packed fence system with everything you need to make your own DIY chain link fence
* Galvanized steel is unmatched in durability and weather resistance, and the shiny silver finish looks great
* Technical specifications: 11.5 gauge, 2 inch woven diamond opening chain link mesh; Product dimensions: 6 x 50 feet
business, construction site, or more
* Works best when combined with ALEKO brand chain link posts and top rails, sold separately, to make a full chain link fence system
* Also sold as a pre-packed fence system with everything you need to make your own DIY chain link fence
* Galvanized steel is unmatched in durability and weather resistance, and the shiny silver finish looks great
* Technical specifications: 11.5 gauge, 2 inch woven diamond opening chain link mesh; Product dimensions: 6 x 50 feet
Specification
|
Alloy
|
Galfan galvanized alloy wire, Zn-10%AL
|
|
Tensile Strength
|
Tensile strength 350-550N/mm2 per EN 10223-3:2013
|
|
Mass of GALFAN
|
Galfan coating meets EN 10244-2 (table 5 - class A)
|
|
GALFAN Adhesion
|
Galfan adhesion meets EN 10244
|
|
Accelerated Test
|
Out wearing accelerated test is per EN ISO 6988
|
|
Wire Mesh tensile strength
|
The nominal tensile strength of the wire mesh is as per EN 10223-3:2013.
|
|
Wire mesh punch strength
|
The punch strength of the wire mesh is as per UNI 11437 and ISO 17746.
|
|
PVC crack test
|
When the mesh is tested at 50% of the nominal tensile strength in accordance with EN 10223-3:2013, the wires will not show cracks
in the organic coating within the double twist region.
|
|
Roll of Chainlinked
|
25x1.5, 50x1.5 or customized
|
|
Steel Wire diameter
|
2.0, 3.0, 4.0, 5.0
|
|
Steel Wire surface treatment
|
Galvanized
|
|
Mesh Size
|
50x50
|
|
Coutry of Origin
|
China
|
|
Manufacturing Style
|
woven
|
|
Chain Link Fence Spesifications
|
|
|
|
|
||||
|
Material
|
Galvanized or PVC coated
|
|
|
|
||||
|
Surface Treatment
|
Galvanization, Hotdip, PVC dipping, PVC paint
|
|
|
|
||||
|
Wire Diameter
|
1.0 - 6.0mm
|
|
|
|
||||
|
Aperture
|
20x20mm, 40x40mm, 50x50mm, 60x60mm, 80x80mm, 100x100mm, etc.
|
|
|
|
||||
|
Roll Height
|
0.5 - 6.0M
|
|
|
|
||||
|
Roll Length
|
4- 50M
|
|
|
|
||||
|
Pole Diameter
|
32, 42, 50, 60, 76, 89mm, etc.
|
|
|
|
||||
|
Pole Thickness
|
1.5, 2.0, 3.0, 4.0, 5.0mm etc.
|
|
|
|
||||
|
Chainlink Roll Sizes
|
|
|
|
|||
|
Aperture
|
Wire Diameter
|
Width
|
Length
|
|||
|
mm
|
mm
|
m
|
m
|
|||
|
40x40
|
1.8-3.0
|
0.5-4.0
|
5-25
|
|||
|
50x50
|
1.8-3.5
|
0.5-4.0
|
5-25
|
|||
|
60x60
|
1.8-4.0
|
0.5-4.0
|
5-25
|
|||
|
80x80
|
2.5-4.0
|
0.5-4.0
|
5-25
|
|||
|
100x100
|
2.5-4.0
|
0.5-4.0
|
5-25
|
|||
Company Profile
Thanks for your interest in Tianjin Cn-Gabion Co., Ltd. Cn-Gabion is a professional wire mesh products manufacturer that supplies you better solutions and the quality wire meshes. This is your one-stop wire mesh solution provider. Be assured that our dynamic team is always moving forward, researching, and seeking to provide you with only the best. Cn-Gabion, originally founded in 2011, has been the leading manufacturer of wire mesh products. We are well respected in the industry for being trustworthy in quality and service. To meet and exceed customers' expectations have been our core value since establishment, which promotes our senior executives to make proactive changes constantly in the market. Our mission is to deliver values for our customers by providing them superior quality, exceptional service and competitive pricing, which brings you a competitive advantage in the market. We devote ourselves to becoming an indispensable wire mesh supplier to customers and to meet their demands and exceed their expectations in quality, delivery and cost through continuous improvement, innovation and customer interaction.
Packing & Delivery
FAQ
-Q-: What makes your fence products different from other company’s?
-A-: CN-Gabion fence provides free design service, customization and warranty service, with strictly quality control and very competitive price.
-Q-: Can I get a pcs of your products sample?
A-: Yes, free samples will be provided anytime.
-Q-: What type of materials do you use for fence?
A-: Most of the wire we use is low carbon steel wire. The core wire for razor wire is high tension strength steel wire. Post
material is Q235.
-Q-: Will my fence rust, peel, fade or chip?
A-: It shows more details in our warranty policy. If without man-made crash, punch, acid wash, etc, the surface can last for more than 10 years.
-Q-: What are fittings and how are they used?
-A-: We have hundreds of fittings for our fence products. Different type of fence comes with different accessories
-A-: We have hundreds of fittings for our fence products. Different type of fence comes with different accessories
-Q-: How do I take care of my new fence?
-A-: Just try to avoid man-made crash, acid, etc.
-Q-: What type of fencing does Cn-Gabion FENCE offer?
-A-: Our mail products are welded mesh fence, double wire fence, 358 high security fence, chain link fence, temporary fence, portable fence, airport fence, barbed wire, concertina razor wire, razor wire fence and gabion box, etc.
-Q-: What types of payment do you accept?
-A-: We accept T/T(30%/70%), L/C at sight, cash.
